Model 1
Three - tooth Cutting Edge: The three - tooth per group cutting edge design in this tct hole saw helps prevent tooth breakage during heavy - duty cutting operations.
25mm Effective Length: Allows for cutting a wide range of materials, from curved thick steel plates to thick metal sheets when using this tct metal hole saw.
Safety Stop: The safety stop at the hole saw's bottom prevents the saw from cutting beyond its 1 - inch (25mm) effective depth, a crucial feature in tct hole saws.
Universal Accessories: The ejection spring, 6mm centering drill, and screws are suitable for all sizes, providing convenience and flexibility in the tct hole saw set.
Model 2
Anti - vibration Design: The uneven cutting edges and integral shaft in this tct hole saw effectively reduce vibration and resonance during cutting.
Tungsten Carbide Tips: Special tungsten carbide tips in this tungsten carbide hole saw set offer excellent blade life and cutting performance.
Safety Coupling Stop: Prevents over - cutting, ensuring safer and faster operation in tct hole saws.
Self - ejecting Plug Removal: Facilitates easy removal of the cut plug in this tct hole cutter.
|
ITEM |
T.C.T. Hole Saw B-T1 Type |
|
|
DIAMETER |
Body Combined |
14mm-70mm 9/16"~2-3/8" |
|
Body Separated |
73mm~152mm 2-7/8"~6" |
|
|
FULL LENGTH |
108mm |
|
|
EFFECTIVE LENGTH |
25mm |
|
|
SHANK DIAMETER |
Body Combined |
10mm |
|
Body Separated |
13mm |
|
|
APPLICATION |
Thick steel sheet Stainless steel sheet Enamel Steel sheet Aluminum sheet |
|
|
ITEM |
T.C.T. Hole Saw B-T3 Type |
|
|
DIAMETER |
Body Combined |
14mm-70mm 9/16"~2-3/8" |
|
Body Separated |
73mm~152mm 2-7/8"~6" |
|
|
FULL LENGTH |
84mm |
|
|
EFFECTIVE LENGTH |
12mm |
|
|
SHANK DIAMETER |
Body Combined |
10mm |
|
Body Separated |
13mm |
|
|
APPLICATION |
Maximum thickness of 5mm Non-ferrous light metals Stainless steel Aluminium Cast lron Steel sheet PVC For all kind or wood |
|
- 3-ply cutting edges prevent cutters broken even in heavy-duty use.
- 25mm effective length enables cutting ranging from thick steel sheet to thick metal pipes with curved surface.
- The abrasion reducing design increases its durability with easier and faster cutting capability.
- Ejector spring, pilot drill bit and screw are fixed together for all diameters
- Thick steel plate,metal pipes
- Stainless steel sheet,enameled
- Steel sheet,aluminum sheet
